Chains, which are the main working link of each chainsaw, wear out very quickly with active use of the device. But don’t rush to go to the store for a new chain - you can always bring it back to life by sharpening it using special equipment. This is the so-called chain sharpening machine. The device is not the most expensive, but if you use a chainsaw often, then it is worth spending money on it - it will save you a lot of money. To make it easier for you to make a choice, we present in this material a rating of the best machines for sharpening chainsaw chains.

Distinctive features of automatic chain sharpening machines

Sharpening a chainsaw chain on a fully automatic machine is performed without direct human intervention. This type of equipment has a completely professional purpose and is used at large logging enterprises. It is advisable to use it in repair shops, which involve large volumes of sharpening work. The machine for sharpening carbide-tipped circular saws is presented only in an automatic version.

The chainsaw chain is installed on the machine manually. Next, you configure certain parameters and start the device for operation. The working bodies move using hydraulic drives controlled by the controller. The chain is sharpened by two heads simultaneously. The upper element is used for the cutting tooth, and the lower one serves as a cut depth limiter.

After setting the value on the machine manually, sharpening occurs fully automatically

Important! The chain is sharpened on both sides in one pass due to the fact that the upper head rotates in both directions.

Automatic machines for sharpening chainsaw chains are characterized by versatility, reliability, durability, high quality and speed of operation, and an increased level of safety. The main disadvantage is the high cost of such equipment, which is unjustified for private use. Such professional machines for sharpening chainsaws also provide standard finishing of each saw link without taking into account the degree of wear of the element according to a single pattern, which can negatively affect the period of further operation of the working part of the saw.

Important! The automated process of sharpening chainsaw chains reduces the working life of the equipment by 15-20%.

Models of sharpening machines for chainsaw chains: power up to 200 W

No. 7 - Patriot MG 220

Patriot MG 220
This machine is ideal for those who constantly work with a chainsaw and, naturally, regularly need to sharpen the chain. Moreover, the model is universal and can handle sharpening chains of absolutely any type and size.

The model is stationary, the power is only 90 W, and the rotation speed of the disk used for processing the chain and having a diameter of 105 mm is 5000 rpm. The list of accessories also includes a protective screen that protects the technician from chips and sparks. A special casing for protection is also responsible for safety. The machine makes noise at 93 dB.

As buyers write, this machine is easy to operate and understanding its operating system will not be difficult. The device copes with the task of sharpening a chain without much difficulty. One of the disadvantages is the difficulty of replacing the sharpening element itself. But the price of the device starts from only 2000 rubles.

pros

• doesn't vibrate
• does not make unnecessary noise
• easy
• compact dimensions
• clear and simple instructions

Minuses

• Difficulty when replacing the sharpening disc
• unreliable plastic case

Prices for sharpening machine Patriot MG 220

Patriot MG 220

No. 6 - DDE MSC-104-95

DDE MSC-104-95
Compact and easy to use machine for daily use with moderate power of 95 W, perfect for home use. The model operates from an electrical network; the sharpening process occurs thanks to a sharpening wheel with a diameter of 104 mm. The rotation speed of the working disk is 5000 rpm, and the noise emitted by the sharpener is 90 dB. Landing 22 mm.

This model is often found in small repair shops, as well as in logging sites, where chainsaws are actively used for work. It is inexpensive but effective, so it is in demand and trusted by customers. Users write that the device is fully consistent with the price-quality ratio. The power is a little lacking, especially if you have to work a lot on the machine, but given the price of the device, you can turn a blind eye to this. The price starts from 2400 rubles.

pros

• cheap option
• compact dimensions
• LED lights
• quiet operation
• ease of use

Minuses

• power is not enough
• short power cord
• not the best build quality

Prices for sharpening machine DDE MSC-104-95

DDE MSC-104-95

No. 5 - Diold MZ-0.13

Diold MZ-0.13
Compact and very inexpensive machine with a motor power of 130 W. It has a low rotation speed, but in general this model is suitable for those who plan to use it infrequently and only at home.

A grinding wheel with a diameter of 10 cm can be installed on the model. The so-called landing diameter is 10 mm. The rotation speed of the grinding disc is 2500 rpm. The cost is just over 2000 rubles.

As buyers write, the model works quite quietly, it is easy and quick to set up and easily copes with the task of sharpening a chain. The base is cast, reliable, and can be additionally screwed to the workbench for convenience. By the way, users advise setting the model immediately to the minimum level of sharpening in order to extend the life of the chain. One of the minuses is the presence of a small backlash, which generally does not affect the operation of the machine.

pros

• cheap
• works great
• quiet
• easy to set up
• quite powerful option
• compact

Minuses

• there is a slight play

Prices for sharpening machine Diold MZ-0.13

Diold MZ-0.13

No. 4 - Oregon 220 VOLT 590181

Oregon 220 VOLT 590181
This is one of the expensive options for chain sharpening machines from a well-known brand, used in domestic conditions. But on the other hand, it is compact, convenient, can easily fit even in a modest-sized workshop, and is very reliable.

The Oregon chainsaw chain sharpening machine is perfect for renewing chains with a 1.1-2 mm drive link. The frequency with which a disk with a diameter of 105 mm rotates is a considerable 5000 rpm. Motor power is only 85 W. The bore diameter is 22.2 mm. The cost is almost 10 thousand rubles.

As buyers note, the model is compact, lightweight, comfortable and ergonomic. It has excellent build quality, and the manufacturer inspires confidence. But the price is too high - after all, you will have to overpay a lot of money for the brand. A machine with similar characteristics can be purchased several times cheaper.

pros

• high build quality
• famous brand
• reliable
• ergonomics
• small sizes
• durable

Minuses

• very expensive
• low power

Prices for sharpening machine Oregon 220 VOLT 590181

Oregon 220 VOLT 590181

No. 3 - Sturm! BG60016

Sturm!
BG60016 Machine from one of the most famous manufacturers of power tools on the Russian market. It is considered one of the most convenient, reliable, and at the same time has high power. An excellent option for home use.

The device is very powerful - 160 W. And the speed of a diamond or abrasive disk with a diameter of 100 mm used for sharpening is 3000 rpm. The bore diameter is 10 mm.

This is a convenient machine that is generally not expensive (the price starts from 3,000 rubles), but enjoys the trust of customers because of the brand. It is not difficult to assemble and prepare for use, and is easy to configure. In general, the quality of sharpening is excellent - none of those who wrote reviews complain. The device is very reliable and will serve you for several years without problems.

pros

• inexpensive
• famous brand
• easy to prepare for work
• reliable
• high power

Minuses

• not detected

Prices for sharpening machine Sturm! BG60016

Sturm! BG60016

No. 2 - Safun CSH-150-104

Safun CSH-150-104
A very inexpensive but powerful version of the machine for sharpening anything, including chains. Users choose it for its good technical characteristics.

The power of this model is 150 W, the rotation speed of the sharpening wheel is 5000 revolutions per minute. The model is easy to install, adjust, and configure. Virtually no vibration. bore diameter 22.2 mm. And the diameter of the grinding wheel used is 104 mm.

As users note, this is a simple and high-quality model. The cost is around 2000 rubles. This is a very low price, which attracts most buyers. Of course, this is not a professional machine, but it is ideal for home use without excessive use. An excellent option for zealous owners.

pros

• very cheap
• good build quality
• easy to use
• compact
• good technical characteristics
• presence of a protective casing

Minuses

• not detected

Prices for sharpening machine Safun CSH-150-104

Safun CSH-150-104

No. 1 - Huter ECS-100

Huter ECS-100
A good machine for use in home workshops, garages, and country houses. The diameter of the grinding wheel is 108 mm, the landing wheel is 23 mm. The engine has a power of 100 W, and the number of disk revolutions per minute is 5200 units.

This is a convenient device that will allow you to quickly sharpen your saw chain. It must be secured to the workbench before starting work. Depending on the type of chain, it is not difficult to adjust the model to the desired option for more efficient operation - the controls are simple. Moreover, it can be easily adjusted to different rotation speeds depending on the type of chain links.

This is a lightweight model that has special protection, ensuring safe use of the device. The service life, according to reviews, is long. The quality of sharpening is also excellent. In short, this inexpensive machine has practically no downsides. The cost of the model is from 2300 rubles.

pros

• excellent sharpening quality
• low price
• safety of use
• good build quality
• compact dimensions
• copes with various sharpening options - multifunctional

Minuses

• not detected

Prices for sharpening machine Huter ECS-100

Huter ECS-100

Reviews of the Huter ECS-100 sharpening machine

No. 8 – Gardenlux (GL) BG100-240

Price: 2000 rubles

Sharpening machine with aluminum base and two sharpening discs included. The idle speed is 6300 rpm, the power is 240 W, such capabilities are enough to solve problems of almost any complexity, sharpening takes a minimum of time and is efficient.

This beauty weighs only 2.5 kilograms - light and mobile. The device is built to last, and it comes with a 12-month warranty—you don’t have to worry that the device will break down ahead of time and your money will go down the drain.

You may be interested in: Top 10 best unicycles according to owner reviews in 2020

The main problem seems to be a very short power cord; the outlet should be located in close proximity. Otherwise, it’s very solid, and the excellent price-quality ratio makes the device one of the most popular models in 2020.

Gardenlux (GL) BG100-240

Models of sharpening machines for chainsaw chains: power over 200 W

No. 4 - Soyuz TSS-60013

Soyuz TSS-60013
This machine is a real find for those who often need to sharpen chains for chainsaws. It is powerful, reliable and very inexpensive. In addition, it is easy to adjust and convenient to use.

The power of this particular option is 220 W, the rotation speed of the circle is 7500 rpm. You can install a circle with a diameter of 10 cm on it, and the landing diameter is 10 mm. The device is equipped with convenient and very simple adjustment mechanisms and allows you to easily set the desired parameters, ideal for sharpening a specific product. If desired, the machine can be securely mounted on a workbench or in another place.

Users who have used this model write that it is easy and simple to set up. It doesn’t make much noise, doesn’t take up much space, is cheap and does its job perfectly. But the build quality leaves much to be desired. The cost starts from 2100 rubles. Recommended for purchase.

pros

• low cost
• high power
• ease of setup
• compactness
• nice appearance
• sharpens perfectly

Minuses

• not the best build quality

Prices for sharpening machine Soyuz TSS-60013

Soyuz TSS-60013

No. 3 - Champion C2001

Champion C2001
A household type machine in the middle price category. It is suitable not only for sharpening chains, but is useful for increasing the sharpness of other cutting objects. It is actively used in everyday life.

Power - 230 W, diameter of the circle used for turning - 145 mm, seat - 22.2 mm. The rotation speed of the grinding wheel is 3000 revolutions per minute.

This is the “Chinese”, which is chosen by buyers for its greater power. But it does not have high build quality. The included discs are unreliable and should be replaced immediately. It is easy to maintain, the engine installed is not bad. The device is suitable for household and infrequent use only. The cost is almost 7 thousand rubles.

pros

• good characteristics
• high power
• easy maintenance
• for home use

Minuses

• Expensive
• not the best build quality

Prices for sharpening machine Champion C2001

Champion C2001

No. 2 - Caliber EZS-220

Caliber EZS-220
This sharpening machine was created specifically for sharpening chains for both electric and gasoline saws. The motor power of the device is 220 W, and the diameter of the grinding wheel is 10 cm (an abrasive disc is used). Its rotation frequency is 7500 revolutions per minute. The sharpening wheel will easily process metal and make the chain effective again when cutting wood. Bore diameter 10 mm.

The design of the model is thought out to the smallest detail: a reliable base that provides maximum stability makes it safe to use. The model can also be additionally secured to a workbench using bolts. By the way, this machine is equipped with a transparent protective screen - it will allow you to observe the process without being covered in chips.

Users write that the model really handles sharpening chains without difficulty, is very easy to operate and is cheap. You don’t need to have any special skills in sharpening chains to use this device - the main thing is to study at least some instructions for use before doing so. Cost - from 2150 rubles.

pros

• there is a protective screen
• sharpens chains well
• low price
• simple controls
• reliable

Minuses

• there is disc vibration
• household, not professional model

Prices for sharpening machine Caliber EZS-220

Caliber EZS-220

No. 1 – Whirlwind SZTs-200

Whirlwind SZTs-200
A powerful and at the same time very inexpensive option on a metal base, which will perfectly cope with the tasks of sharpening saw chains. The motor power is 200 W, the model has a bore diameter of 10 mm. And the diameter of the circle used in the work is 10 cm. The rotation speed is 6000 rpm.

A lightweight, functional and reliable model that will cost the buyer a very small amount. But preparing it for work is not easy, according to customer reviews. And when the device is configured correctly, it will easily sharpen chains, files, and other household items. Unfortunately, buyers note that some design elements are loose, and the model also needs to be slightly modified to suit itself. Overall, considering the low cost, this is a great machine. Cost - from 2000 rubles.

pros

• excellent sharpening quality
• cheap
• powerful
• universal
• compact and lightweight

Minuses

• needs improvement
• there may be gaps

Prices for sharpening machine Vikhr SZTs-200

Whirlwind SZTs-200

Reviews of the sharpening machine Vikhr SZTs-200

The operating principle of manual machines for sharpening chainsaw chains

How is the chain itself made? It consists entirely of metal, and a special steel alloy, strong, resistant to impact and reliable. The outside usually has a special hard coating that helps extend the life of the saw chain itself. So, its basis is a lot of cutting, very sharp teeth, which are located on both sides of the chain, alternating with each other. They are connected through special links into a single whole.

This is what the sawing link of a chainsaw chain looks like

But no matter how good and expensive a chainsaw chain is, it still becomes dull during use. Reasons for dullness:

• intensive saw work;
• touching the cutting blade to the ground or other hard objects.

Important! The effectiveness of the chain depends on how sharp the teeth are.

It is easy to understand that the chain has become dull: work productivity drops, the saw itself begins to vibrate strongly, it moves from side to side, very small chips appear, and dark ones at that. And it is not recommended to use such a saw before sharpening the chain - a dull chain increases fuel consumption, and also causes unnecessary vibrations and rapid failure of the saw itself.

Machines for sharpening chainsaw chains are devices that are very necessary for every owner of such a saw if he uses it more or less often. In appearance, they look like a regular cutting saw, but instead of a cutting disk they are equipped with a special sharpening blade. Any model also has a special support frame, on which the chain itself is fixed during sharpening. When such a device operates, its disk alternately passes over each of the links-teeth of the saw chain, sharpening them.

Sharpening machine for chainsaw chains HAMMER SPL105

But before sharpening, the main thing is to set up any machine correctly. A certain angle must be maintained between the plane of the rotating disk and the link of the chain itself. It mainly depends on the pitch of the links. By the way, it is recommended to secure the machine well on the workbench before starting work. This will help protect yourself from accidental injury, and will also allow you to work comfortably. Also, any model of sharpening machine is equipped with a special casing that will protect the master himself from unpleasant situations - sparks getting on clothes or metal shavings getting into his eyes.

On a note! Typically, a 3.5 mm thick wheel is used to sharpen a chain. It is located perpendicular to the chain itself. It is most convenient to set the working angle on models that have a special graduated scale.

Typically, a sharpening machine is a small and lightweight device that is not difficult to understand. There are both household and professional options. An inexpensive household model is quite enough for the home. In general, such machines are usually used in the construction, logging or woodworking industries. Can be used in various workshops.

How to choose a machine for sharpening chainsaw chains: important recommendations

To decide which machine to choose for sharpening chainsaw chains, you should first consider the main indicators of the equipment. First of all, it is necessary to clarify the diameter, thickness and rotation speed of the sharpening disk. The latter indicator indicates the performance of the device and the rate of metal removal from the cutting surface of the tooth. The optimal value is 30-35 m/s. This parameter is not indicated by the manufacturer, but it can be calculated mathematically, knowing the rotation speed of the disk and its diameter.

When choosing a machine for sharpening chainsaw chains, you need to pay attention to the thickness, diameter and rotation speed of the disc.

The next important criterion is the power of the machine. This figure should be in the range of 85-180 W, which is quite enough. This is explained by the fact that the disc is in contact with the metal tooth for a few seconds, so the equipment does not need high power to carry out the sharpening process efficiently.

Helpful advice! If the machine model has a power of 400 W or more, this parameter is redundant. In this case, this device is recommended for sharpening knives and any metalworking tools.

When choosing a device for sharpening chainsaw chains, you should pay attention to the equipment included. In addition to the machine, the design may include a set of abrasive discs of various thicknesses, templates, test gauges and other keys.

Important! The machine must have a protective screen, which is the main safety requirement.

When buying a chain sharpening machine, you must check the motor mount and guide for any play.

It is necessary that the machine be equipped with mechanisms that facilitate and speed up the sharpening process, in the form of a device for tensioning the chain, a synchronizer for automatically locking the teeth when lowering the sharpening disk, a mechanism for moving the chain and a device for clamping it. The machine can be fixed to the horizontal part of the workbench or to a vertical wall.

When choosing a machine, you need to check the mounting location of the motor and guide for any play. Their presence is evidence of low-quality equipment that is unable to perfectly maintain the sharpening angle of the chain.

Types, tips for choosing

All types of similar devices used for working with saw chains should be divided into two main categories - automatic and manual. Detailed descriptions of both types are given in the table.

Table. Manual and automatic options: descriptions.

Manual chainsaw chain sharpening machine

No. 5 – VORTEX SZTS-200

Price: 2400 rubles

A domestic machine for sharpening chains of electric and chainsaws, which pleases customers with an impact-resistant housing that reliably protects the motor from damage.

You may be interested in: Rating of the best professional hair clippers

Despite its modest dimensions, the device’s engine turned out to be quite powerful – 200 W. The revolutions are also at the level of 6000 per minute, the machine operator is reliably protected by a transparent casing, sparks will not fly into the eyes or onto clothes.

Among the disadvantages are mainly the lack of backlight and useless instructions that do not give any understanding of the operation of the machine.

VORTEX

How to choose the right sharpening machine, selection criteria

Let's figure out what needs to be taken into account when choosing a machine to improve the sharpness of the chain. There are several criteria:

• Device power. One of the most important parameters. It should be greater, the more often and more intensively the machine itself is used. The speed of sharpening and the efficiency of the process depend on this parameter. Devices with an indicator value of less than 200 W are considered low-power models. For normal use at home, a power option of 200-220 W is sufficient, or even less - it all depends on how often you use the saw itself and how often you need to sharpen the chain. For professional use, you will have to buy a device with a power of at least 500 W.
• Rotation speed and type of spindle (working element). The productivity of the machine greatly depends on these indicators, since the faster the grinding wheel rotates, the faster the chain is sharpened. The optimal speed option can vary between 3500-7000 rpm. If you will be working on the device frequently, then you need to choose a model with higher performance.

Chain mounted on a sharpening machine

• Diameter of the circle used. For using the machine at home, a model with a circle diameter of around 10 cm is quite suitable. And in enterprises and large workshops, the circle can have a diameter of 500 mm.
• Efficiency and the presence of a number of other functions. Such a machine is often used not only for processing the sawing part, but also performs a number of other functions: for example, it is used for sharpening other equipment. It will also be good if it has functions such as chain adjustment, clamping, grinding, tension adjustment, etc.

Attention! The more powerful, efficient and functional the machine, the more expensive it will cost. Therefore, it is important to consider whether certain features will be needed before making a purchase.

№2 – REZER EG235-CN

Price: 5500 rubles

A machine of Chinese-Russian origin, captivating with its very quiet operation and almost zero vibration. Conveniently assembled, installation on a workbench takes no more than a minute.

You may be interested in: Top 10 best deep fryers for home 2020

There is a backlight, the clamp guides are made of high-quality steel - they will last a long time. In general, a very solid option that can serve you faithfully for many years.

There are some flaws - the plastic frame, as well as the flimsy fastening of the protective casing, do not add points to this machine. The device weighs almost eight kilograms.

REZER EG235-CN
