Double-leaf gates have been tested for thousands of years in all climate zones, from the Arctic to deserts. There is no design more reliable and easier to manufacture. Modern swing gates are equipped with a mechanical device for opening and closing. The only thing in which swing doors are inferior to sliding and lifting doors is the mandatory presence of free space for opening the doors.
When sheet metal became available to everyone, fencing began to be made from it. Swinging metal gates with a wicket, made of corrugated sheets on an iron frame, are found at the entrance to most industrial areas and private properties.
Advantages and design features
In some places there are still gates made of inch planks with forged hinges and locks. Country club owners are willing to pay a lot of money for such exotica. As a rule, the gate was located next to the old wooden entrance. Opening the heavy doors is an almost ceremonial process.
Now they are making metal gates with a wicket in the wing. Welding a frame from a profiled pipe or angle is easier than making additional support for the gate. The advantage of this particular design is that opening the gate does not require additional space. The gate opens in the area of the gate leaf.
The wavy surface of the corrugated sheet only increases the rigidity of the entire structure, which is especially important in conditions of strong gusts of wind or slanting rain.
If there is no automatic opening mechanism, the doors swing open 90 degrees manually. Heavy gates may have a roller installed at the bottom to make it easier to move the edge to the desired distance. It is advantageous to install swing gates for businesses in places where they are rarely used. If there is a large flow of vehicles or people, automated sliding gates are economically feasible, despite their high cost.
In private properties, simple swing gates are appropriate if they are used during a short season. Mechanisms for opening and rolling back the sash should not be left unattended for a long time.
A gate in the sash is needed to open the main locks. For reliability, they are located inside the territory. If the bolt runs across the entire width and is fixed on the support posts, it is impossible to open the gate from the outside.
Swing gates without automatic opening are the cheapest not only to manufacture, but also to operate.
Electricity, regular technical inspections, and repairs of the electromechanical drive and moving parts are not required.
The price of a standard garage door includes:
✧ Box: from a corner 50x50x 5mm. (or professional pipes 50x50x 3mm. )
✧ Doors and stiffening ribs: made of profile pipe 50 x 25 x 2mm.
✧ Steel sheet: 2mm, ( outside )
✧ 4 loops ( on a 36mm support bearing)
✧ 2 garage bolts 20mm.
✧ Eyelets for a padlock with a 16mm hole.
✧ Painting: Nitroenamel primer-enamel 3in1 free !!!
.
Garage doors with double frame and response frame
Gates with wider opening and increased height
Steel swing garage doors in Moscow and the Moscow region are the simplest and at the same time reliable design. They are easy to use and can be installed in openings of any size ( it is possible to install gates in Moscow and the Moscow
region by widening the opening and raising the beam
). The final cost of the gate will be determined by the area of the leaves and the quality of the materials from which they are made. The installation conditions on site will have a certain impact on the overall price of a garage door installation.
Swinging industrial gates for production
Fire gates
Swing gate designs have been used by people for several centuries, but have not yet lost their relevance. The production and installation of metal swing garage doors in Moscow and the Moscow region is increasing in volume, and this is a direct indicator of the high demand for such products.
Metal gates to a wooden garage
Swing gates for a metal garage
Selection of materials for the frame, pillars and panel
Iron gates place more load on the supports than wooden gates. After the opening and closing cycle is completed, the frame will vibrate for a while. The sheet of corrugated sheets experiences significant wind loads and also vibrates under the pressure of the elements. Therefore, supports for iron gates must be iron, reinforced concrete or made of brick. Even for a dacha, it is more advisable to make swing gates and wickets metal.
Wooden posts may be at wooden gates. If they are made of lightweight materials, wooden supports are acceptable. Wooden posts are suitable for shutters made of picket fence, clapboard or chain-link mesh on wooden frames.
Wooden supports must be treated with bioprotective impregnation or coating must be used to the depth of the support's immersion in the ground. The upper part of the support is impregnated with bioprotective and moisture-resistant compounds or painted with paint for external use. Cheap wood used for fencing is not durable. Therefore, after just 3-4 years, the wooden frame will warp, the screws and nails will rust and begin to fall out of their fastening points.
Doors on a wooden frame are suitable for temporary fencing because they are easy and inexpensive to make. They block access to construction sites and repair work sites.
Metal gates and gates made of welded mesh
A gate is not just a door, it is an entrance to your property, which must certainly be reliable. At the same time, the gate also serves as a kind of decoration for the site, making it unique and especially attractive.
offers the production and installation of metal gates made of welded mesh, which are an ideal budget option for the entrance to fences made of chain-link mesh or mesh fences.
We also offer you the installation of sliding gates and swing gates, both mechanical and automatic with electric drive.
Advantages of metal gates and welded mesh gates
- Metal gates and gates do not interfere with the penetration of sunlight - plants, trees, shrubs and flowers in your garden will receive enough light for active growth, timely flowering and ripening.
- Reliable and durable - being made of galvanized profile pipes with panels filled with mesh, metal gates retain their strength characteristics for many years.
- They have high color fastness - you can order a metal gate made of welded mesh, painted in any color according to the Ral scale. The coating warranty issued by the manufacturers is 10 years.
- Requires minimal care.
- They are distinguished by ease of installation - our company’s specialists will install a metal gate or a gate made of welded mesh in the shortest possible time.
Prices for fence posts
| vendor code | Height | Price with plug | Price with ball |
| str_100x100x3_L2000 | 2m | 1050 rub. | 1250 rub. |
| str_100x100x3_L3000 | 3m | 1400 rub. | 1600 rub. |
| str_60x60x2_L2000 | 2m | 470 rub. | 620 rub. |
| str_60x60x2_L3000 | 3m | 700 rub. | 850 rub. |
| str_60x60x3_L2000 | 2m | 570 rub. | 720 rub. |
| str_60x60x3_L3000 | 3m | 850 rub. | 1000 rub. |
| str_80x80x2_L2000 | 2m | 630 rub. | 830 rub. |
| str_80x80x2_L3000 | 3m | 950 rub. | 1150 rub. |
| str_80x80x3_L2000 | 2m | 900 rub. | 1100 rub. |
| str_80x80x3_L3000 | 3m | 1200 rub. | 1400 rub. |
| sts_102x35_L2000 | 2m | 900 rub. | 1100 rub. |
| sts_102x35_L3000 | 3m | 1200 rub. | 1400 rub. |
| sts_89x35_L2000 | 2m | 850 rub. | 1050 rub. |
| sts_89x35_L3000 | 3m | 1140 rub. | 1340 rub. |
Benefits of cooperation with us
We guarantee the highest quality not only of the materials from which the gate is made, but also of the installation work - the company’s specialists have quite a lot of experience in this field, which is confirmed by hundreds of satisfied customers.
In addition, we are ready to offer all interested parties the opportunity to order various types of fences - from simple to the most complex - for us there are no difficulties in the manufacture and installation of structures of any design and scale.
You will be pleasantly surprised by the cost of metal gates made of welded mesh in, as well as the deadlines for completing the work! Contact us!
Requirements for swing gates for a summer residence
There are two restrictions for gates on a summer cottage: the size of the driveway and the size of the site itself. It is necessary to provide for the possibility of entry of not only personal transport, but also special equipment, for example, a truck with humus. In many old gardening partnerships, the passages between plots are very narrow, so turning around to enter the plot is not an easy task. All this must be taken into account when making measurements. On a narrow country street, it is necessary to provide the ability to open the doors a full 180 degrees.
Swing gates consist of two leaves that hang on hinges attached to posts installed along the edges of the gate opening.
A gate on a country gate is often a necessary necessity. There may be no space for a gate in the fence, and there may not be room on the property for opening and passage. Country metal swing gates with a wicket can be shorter than human height. For rigidity, a strong rectangular or shaped frame is made in the gate sash.
It is up to the dacha owner to decide whether to make a gate panel from corrugated sheets, weld a lattice with an interesting pattern from reinforcement, or use a construction lattice to open a view of the flower beds. It depends on the situation in the surrounding villages and towns. Arriving at the opening of the summer season, a summer resident may find that his iron gate has been cut down. A smart solution would be to choose a material that is unattractive to scrap metal collectors and will mask the iron parts. This could be siding, wooden panels made from slabs or clapboards. In holiday villages with reliable security, metal gates made of corrugated sheets will last longer than any other.
If you are planning winter trips to the dacha, you should leave a large gap between the ground and the bottom of the swing doors. The closer they are to the ground, the more snow will have to be dug up to enter the site.
Types of gates
Usually metal gates with a wicket are installed immediately, but if necessary, the gates can be installed separately, and the wicket at some distance from them. Often a second spare gate is also installed in the fence, for example, to access another street. Gates differ in design, opening system, and material of manufacture. The most common types of opening are:
- swing gates and garden gates: their main advantages are their inexpensive price and ease of installation. The disadvantages include the need to have free space for opening and the need to clear snow from the area in front of them in winter. The main load from the wings of the swing pillars is borne by the support pillars, so close attention is paid to their installation;
- sliding gates and garden gates: a more common system today with one leaf that slides sideways, moving along the fence. The price for such gates and gates for summer cottages is higher, but they do not eat up the free space in the opening area. Sliding gates can be rail or cantilever.
Any type of gate can be equipped with an automatic opening system. allowing you to control opening/closing directly from the car cabin. Structurally, the gate consists of support pillars, a frame, filling of the leaves, fasteners, an automatic and locking system. Depending on the filling material, gates can be transparent (lattice) or solid. Blind gates provide complete privacy to the local area, especially if the fence is also solid. The disadvantage of closed gates is their high windage. Lattice gates are lighter in weight. You can also buy gates with a wicket of a combined type, when the leaves at the bottom are filled with solid filling: for example, corrugated sheets, and at the top they have a lattice structure.
Dimensions and weight
Manufacturers of all types of gates have adopted 4 meters as the standard size. The owner arranges entry to his site based on the location, financial situation, and available materials. Gates for an enterprise must comply with GOST of 2003. Otherwise, there will be a reason for dissatisfaction with various inspections, starting with the fire department.
The inspectors do not inspect private property. But it’s worth looking at GOST when designing your gates. Some characteristics are given ready-made, so you don’t have to do all the calculations from scratch. For example, choosing a profiled pipe depending on the weight of one leaf:
Up to 150 kg – pipe with a cross-section of 80x80mm.
Up to 300 kg – pipe with a cross-section of 100x100mm
More than 300 kg - pipe with a cross-section of 140x100mm
GOST also provides the frame structures of the sashes, with one diagonal or with additional lintels, and their dimensions. By summing up the weight of the frame and corrugated sheeting, we get the approximate weight of the entire product.
The relevant GOSTs indicate the weight of a linear meter of a profile or a square meter of corrugated sheeting, depending on the thickness and cross-section. Since the hinges and latches must be made of iron, their weight must also be taken into account. Calculating the total weight of metal swing gates is not difficult.
iron gates photos and prices
Forging Everyone! Budget forging
We bring to your attention wrought iron gates and gates for your home and garden. The catalog on our website contains photos of forged gates, wickets and their detailed characteristics. The price of forged gates is distinguished by its affordability due to serial production and well-established technologies, and the quality meets international standards or even exceeds them in many ways. You can purchase any products from our company at the lowest prices thanks to the joint purchasing service. Buying forged gates and wickets at a low price is acceptable for people who value their time and money.
Artistic forging of budget iron gates photos and prices is, depending on the customer’s wishes, to make any design, modern smooth lines or the solid simplicity of a traditional solution. Most often, the choice of what to create iron gates from, photos and prices , stops at the profile pipe. Owners of their own homes say iron gates, photos and prices, are the best addition to home design. It has been many years since iron gates photos and prices have become a more simplified art. It is difficult to find a master who will understand and capture your idea. The customer can view sketches of iron gates photos and prices and choose what is more in harmony with his site and wallet when purchasing iron gates photos and prices . From an aesthetic point of view, iron gates photos and prices are an original and unique work of art. Working with artistic forging products, we create wonderful products that fully satisfy your needs and bring aesthetic pleasure to iron gates photos and prices . We work for you at low prices to give you the opportunity to enjoy excellent quality at an excellent price. The price of iron gates photos and prices is the first thing a buyer thinks about. There is an opinion that they are unreasonably expensive. But, you can purchase elegant iron gates with photos and prices inexpensively on our website at an affordable price (from 7,000 rubles). As you can see, you can turn your home into a luxurious palace at the lowest price!
Information on iron gates, photos and prices
Forged gates
,
photos and prices
.
Forged gates
Kazan
price ...
Forged
gates
in Kazan, production and installation,
photo and price
.
Forged
metal gates
with and without a wicket, as well as forged gates separately...
CATALOG FENCE GATES (K№4) | Metal gates
... Price
: 12,940 (rub/m2).
Metal
entry swing garage
.
METAL GATES
WITH FORGING (VKV No. 62).
Price
: 9,865…
Kovka1.ru – Forged metal gates
(
photos
,
prices
).
Sliding gates photo
No. 1.
Sliding wrought iron gates photo
No. 11.
“Hector” in the village of Nikolina Gora, 2007. Sliding forged gates photo
No. 11.
Metal gates
- Victoria Art Metal Victoria Art Metal -
metal gates
and wickets without a single complaint... meters -
the price
of metal swing and sliding gates
price
... like this: “In reality,
metal gates
are better than in
the photo
.”
Metal gates
|
Gate
prices Photo
Production of forged and welded metal
gates
to order.
Prices
for manufacturing and installation
of gates
.
Photos
of our works.
Photo metal gates
|
Photos of iron gates
Iron
metal gates
are reliable, high quality and... Request
a price
...
The photo of
iron metal
gates
shows that now from this...
Photo gallery of metal gates
(catalog No. 6) |
Forged ...
(total
photos
of forged
gates
: 124).
( photo
in catalog No. 6: VK101 - VK120).
Forged
swing
gates photo
(Sketch VK No. 101).
Price
: 10,785 (rub/m2).
Forged swing gates photo
,
photos of
swing gates
...
Forged
metal gates
will serve you for many centuries!
... Forged gates and wickets - prices
,
photos
, drawings and sketches are the property of ...
Home | Index
Norms and technical conditions
When designing and manufacturing swing gates yourself, it is not necessary to strictly follow the requirements of GOST. But getting to know them will make the work easier. When manufacturing to order, it will be easier to coordinate the project with the manufacturer and draw up a competent estimate.
An illustrative example of calculating the width of the passage: the width of the car is within 2 meters, 0.5 m each for free maneuvering. This turns out to be 3 m. This is less than standard ready-made sliding and lifting gates. The location of the gate does not limit the availability of mechanisms for movement. Therefore, it is located where it is convenient. The height of the frame is also determined by the owner of the site. The corrugated sheet can cover the entire area of the frame or only the lower part.
Approved standards and technical conditions should be followed when choosing hinges, locks and when installing automatic opening mechanisms. The main requirement: hinges, canopies, and frames must have a double safety margin. In this case, the sash will not be torn off by an accidental gust of wind.
When installing an electric opening mechanism, all work must be carried out strictly according to the instructions, and the gate parameters must comply with the specifications.
Gates and wickets for a private home
If the choice of gates for a summer house or for a private house is carried out on the basis of the principle of being cheap and reliable, then it is worth choosing swing products. This is a convenient and inexpensive option, the installation of which will not be difficult even if you install it yourself.
Sliding gates can also be opened manually if desired, which significantly reduces the cost of the system. If technical capabilities are available, sliding gates are more preferable, since one leaf is less likely to break the system. Sliding systems, unless they are manually opened, require regular maintenance of the electrical system.
A gate is a necessary addition to any type of gate. It increases comfort of use by allowing pedestrians to enter through a separate opening. The width of the gate is usually designed to be no less than a meter. Metal gates with a wicket are coated with powder paint to improve their anti-corrosion characteristics or are made of galvanized material.
Production
Preparation for the construction of swing gates - drawings and sketches
Preparations for the manufacture and installation of swing gates begin
The gaps between the doors and supporting posts, as well as between the doors themselves, can be closed with special profiles-coverings, which makes swing gates even more elegant.
from measurements. It is necessary to ensure that there are no obstacles in the opening area and that the gate height is sufficient. The width of the posts, gaps, fasteners and hinges is taken into account.
Drawings must be made taking into account exact dimensions. This will allow you to determine the required clearances. There should be a gap of at least 5 mm between closed sashes in case the frame sag. The drawing shows the depth of immersion of the racks and the dimensions of the foundation.
A drawing or sketch is needed to calculate the consumption of materials and their cost at current prices. If used materials are used, it will be easier to find a place for each piece of iron with a drawing.
What you need for work
To make a swing gate with your own hands, you will need ordinary tools. Anyone who has built or repaired anything on their property has them in the garage. A grinder and a welding machine can be rented at the tool rental. But if you don’t have much welding experience, it’s better to invite an experienced welder. This will save time and materials.
Material calculation
Using the previously made drawing, the total length of the frame around the perimeter and the length of the stiffeners are measured. The area of the corrugated sheet is calculated. It should be taken into account that to attach the lock and hinges to the frame, you will need to weld flat plates.
To calculate the materials for the gate, you need to make a drawing based on which the calculation is made. You should take the material in reserve.
If you buy profiles for the frame and cut them yourself, you need to find out what length of rolled metal the local metal warehouses sell. Usually their length is a multiple of 3 meters. It is necessary to leave a diagram for cutting a solid pipe with a small margin for possible defects. This will prevent you from buying too much. Taking into account the costs of transporting long pieces, it can be easier and cheaper to order cutting of a profiled pipe according to the dimensions of the drawing. The frame parts will be of exact dimensions, because cutting is carried out on machines.
Corrugated sheets have standard sizes. Manufacturers indicate the working width - the size taking into account the width of the profile wave, which will disappear when laying overlapping. On the scale diagram of the sheet, you need to make a layout of the panels of the doors and gates. Take into account the profile pitch so that the edges of the sheet are adjacent to the frame.
The number of hinges, bolts, locks and their total cost are calculated. There must be at least three loops on each side. The gate should also have three hinges for the strength and reliability of the lock.
Separately, based on the drawing of the supports, the amount of building materials and their cost are calculated. In price lists, the price of rolled metal is usually indicated per ton or kilogram, the price of corrugated sheets is RUB kW m.
Tools
You will need a set of construction tools for installing racks and a set of tools for working on metal. Be sure to have a building level and a long tape measure.
To install the racks you will need:
- Shovel or hand drill;
- Containers for mixing the solution;
- Tools for making formwork.
For the manufacture and installation of gates:
- Bulgarian;
- Set of slotting discs for metal;
- Set of emery and grinding discs;
- Welding machine;
- Screwdriver;
- Wrenches and screwdrivers.
Installation procedure
Gate installation begins with the posts. The soil for the foundation is excavated to the depth of soil freezing. The foundation can be brick, concrete poured into formwork or soil. Reinforced concrete posts only require a sand bed under the base.
Racks made of logs, timber or rolled metal are lowered into the pit and fixed in a horizontal position. Check the distances between the posts. Then the concrete is poured. After complete hardening, at least a day must pass before hanging the gate.
The most durable welding joint is obtained at an oblique diagonal joint.
If you make metal swing gates yourself, you need to prepare a place for laying out the frame parts. The profiled pipe or angle is cut. The permissible deviation from the dimensions according to the drawing should not exceed 5 mm. The joints are cleaned of dirt and rust.
Frame parts are welded. The seam must be without holes so that water does not penetrate into the frame from the profiled pipe. Stiffening plates and plates for installing hinges and locks are welded, and hinges are welded. The seams are cleaned and coated with varnish or paint to protect against corrosion.
Experts recommend welding the gate leaves at the junction, then marking the installation locations for the hinges. This way the size will be accurately maintained. After hanging, the seam at the joint is sawed through with a grinder.
Places for attaching hinges are marked on the racks. The hinges are attached to the wooden posts with self-tapping screws. The hinge supports are welded onto the metal posts. Welding plates or corners are attached to concrete and brick racks with dowels, and hinge supports are welded to them.
The gates are hung on hinges. The joining of the valves is checked. Then the gate is covered with corrugated sheeting. For convenience, the gate can be removed. Sheets of corrugated sheets are attached to the frame with self-tapping screws or welded.
Installation of a built-in gate
It is more convenient to install the built-in gate before the gate is hung. It is preferable for the gate to open inward. The gate has its own lock and its own key, which is not connected to the gate lock for security. The frame of the gate is inserted into the frame of the sash, hinges and locks are attached. For convenience, the gate can be removed and returned to its place when the gate is ready.
The design options for swing gates are endless. Forged doors or a welded decorative grille will allow you to disguise the gate. If the fence and gate are made of the same corrugated sheeting, the gate is difficult to notice immediately.
The higher and more solid the fence, the more elegant the gate and the more beautiful the view behind it. The classic combination is stone supports and forged doors that swing open automatically.
